A3 Size Multi
A3 Size Multi-Function Phone Case Pen Golf USB Desktop Embossed UV LED Flatbed Printer Price 1. Compact design,Simple an
Basic Info.
| Model NO. | UF-300C |
| Printing Speed | 3 Minutes for A3 Size |
| System Supported | Windows 7, Windows 10, Windows XP |
| Application | DIY Phone Case, Pen, Golf, USB, Acrylic, Wood, etc |
| Resolution | 1440dpi |
| Media Height Detecting | Equipped |
| Rotary Device | Available. for Bottle Printing |
| Warranty | 15 Months Warranty for Our A3 Desktop UV Printer |
| Print Head | 1X Epson Dx8 |
| Color | Cmyk/Cmyk+W |
| Ink | UV Ink |
| Model No. | UF-300c Desktop Embossed UV Printer |
| Size | A3 Size, 30X50cm (A2, A1 and Bigger One Available) |
| Transport Package | L745mm W745mm H730mm / 100kg |
| Specification | L670mm W565mm H635mm / 90KG |
| Trademark | SinoColor UV LED Flatbed Printer |
| Origin | China, Shanghai, Nantong |
| HS Code | 8443322100 |
| Production Capacity | 300 Sets Per Month |
Product Description
A3 Size Multi-Function Phone Case Pen Golf USB Desktop Embossed UV LED Flatbed Printer Price
1. Compact design,Simple and decent2. Maximumly use mold to produce machine components to achieve best resolution.3. Sinocolor System. Much more professional and more stable than desktop modified printer. Control the color freely.4. White ink circulation system equipped. Decrease problem caused by White ink precipitation.
| Model No. | UF-300C | UF-600C | |
| Printhead | Single Epson DX8 | Single Epson DX7 | |
| Resolution | 1440dpi MAX | ||
| Max Speed | 3 minutes for A3 size | 6 minutes for A2 size | |
| Print Head Height | 20cm Max | ||
| Printing Size | 30 x 50 cm Max | 42 x 60 cm Max | |
| Print Direction | Intelligence double sided | ||
| Print Method | micro piezo print technology, intelligence drops transformation technology | ||
| Height Adjust | Electric | ||
| Distance of Print Head Printing | 1-3 mm (1 mm is the best) | ||
| Ink Color | CMYK/ CMYK,LC,LM/ CMYK, White | ||
| Ink Supply System | CISS | ||
| Ink Consumption | 15-20 ml / squre meter | ||
| Min Ink Drop Size | < 1.5 PL | ||
| Interface | USB2.0 | ||
| Rip Software | Maintop (Standard)/ Photoprint (Optional)/ Onyx (Optional) | ||
| Working Environment | Temperature 18-30 Celsius, Humidity 30-70 RH, Clean room, Low dust, Less sun light | ||
| Power | AC 110/220 V, 50 Hz/60 Hz | ||
| Size&Weight | Machine | L670mm W565mm H635mm / 90KG | L800mm×W840mm×H640mm/120KG |
| Packing | L745mm W745mm H730mm / 100KG | L890mm W930mm H750mm / 140KG | |
